DISCHARGING OF CAPACITOR(For Dismantler)


Some Mazda model have a capacitor (i-ELOOP) as an energy regeneration system on the deceleration of the vehicle, and the electricity remains in the capacitor depending on the condition of the vehicle. When an end of life vehicle is scrapped in that condition, the electricity stored in the capacitor could cause an ignition or a fire in shredding the vehicle.

Therefore, please always discharge the capacitor when a vehicle is dismantled.

Also, please read the capacitor discharging manual, and discharge the capacitor safely and properly.

Procedures of discharging the Capacitor


The procedures of discharging the capacitor are available selecting

vehicles and languages by flags shown below.

The procedures of discharging the capacitor are available selecting

vehicles and languages by flags shown below.

De procedures van het afvoeren van de condensator zijn verkrijgbaar selecteren voertuigen en talen door vlaggen hieronder weergegeven.

Les procédures de décharger le condensateur sont disponibles à travers sélectionner des véhicules et des langues par les drapeaux montré dessous.

Die Verfahren, den Kondensator zu entlassen, sind durch unten dargestellte

Fahnen durch auswählende Fahrzeuge und Sprachen verfügbar.

Le procedure di dimettere il condensatore sono disponibili attraverso selezionando veicoli e lingue da bandiere mostrato sotto.

Los procedimientos de desembarcar el condensador están disponibles por

escoger vehículos y lenguas por banderas mostradas abajo.

De förfaranden för urladdning av kondensatorn är tillgängliga väljer fordon och språk genom flaggorna nedan.

电容器强制放电处理要领, 通过选择下列的旗,指定车型和语言能利用

キャパシター強制放電処理要領は下記の旗により、車種と言語を選択して利用できます。




1. Mazda 2 (DEMIO) Vehicle type DJ or DL

      JM*  DJ****** 100001~

      MM* DJ****** 100001~

      3MD DJ****** 100001~

      MM* DL****** 100001~



2. Mazda 3 (AXELA) Vehicle type BM on BN
      JM*  BM****** 100001~
      JM*  BN****** 100001~
      MM* BM****** 100001~
      MM* BN****** 100001~
      3MZ BM****** 100001~
      3MZ BN****** 100001~
      LVR *DFAC**N 300001~



3. Mazda 6 (ATENZA) Vehicle type GJ or GL
      JM*  GJ****** 100001~
      JM*  GL****** 100001~
      RUM GJ****** 100001~



4. CX-3 Vehicle type DK
      JM*  DK****** 100001~
      MM* DK****** 100001~



5. CX-4 Vehicle type GK
       LFP M******1 A10001~



6. CX-5 Vehicle type KE
      JM*  KE****** 400001~
      RUM KE*9***V 000001~
      PP1  KE*****M 100001~
      LVR  HDC****N 010001~



7. CX-5 Vehicle type KF
      JM*  KF****** 100001~
      PP1  KF*****M*10001~
      RUM  KE*W**** 100001~



8. CX-9 Vehicle type TC
       JM* TC ****** 100001~



9. MX-5 (ROADSTER) Vehicle type ND

       JM* ND****** 100001~
